Product Details
Bottle Filling Machine
Brief On Machine
The Premium Filling System consists of main structure, material transfer pump, product transmission belt with adjustable guide, material storage tank, Safety acrylic cover, pneumatic priming & stopping facility, filling pump, isolated transformer, electrical panel, motor, PLC & HMI,AC drive & storage tank. The special HIGH / LOW liquid level indication in the tank is an added advantage.
Salient Features of Premium Bottle Filling Machine
|
The unit is made compact & versatile as per GMP norms |
The structure is made of MS cladding with SS 304 |
|
Rigid vibration free construction for trouble free performance |
The contact parts such as filling nozzle, filling pump are made of SS 316 L |
|
The Excel Filtration are used for the filling purpose |
Easy to clean the base of the machine |
|
The machine is supplied with easy to clean inbuilt storage tank |
The storage tank is connected with the high capacity of material transfer pump |
|
The storage tank is automatically controlled by the mean of float (Level) sensors |
The process of priming, diving and blocking of the products done by pneumatic (air) operated cylinder |
|
The Air pressure indicator attached with the machine to indicate the fault of low pressure of air supply |
There is special feature called "PRIME" which is useful to suck the filling material from storage tank to nozzle end very quickly. More over this facility is useful to clean filling line (Silicon tubes) as well as filling pump |
|
The machine has a facility of using for all the pumps together or individual pumps also |
Easy to operate PLC for any kind of filling volume adjustment |
